ISDA: 9ZND

Deposition Date 2025-12-12

Release Date 2026-09-16

Last Version Date 2026-09-16

Entry Detail

PDB ID:

9ZND

Keywords:

MEMBRANE PROTEIN

Title:

Structure of rabbit RyR1 complexed with FKBP12.6 and calmodulin in the presence of dantrolene, ATP, 4-chloro-m-cresol, caffeine, and Mg2+

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
Oryctolagus cuniculus (Taxon ID: 9986)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.09 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Ryanodine receptor 1
Gene (Uniprot):RYR1
Chain IDs:I (auth: D), J (auth: B), K (auth: A), L (auth: C)
Chain Length:5037
Number of Molecules:4
Biological Source:Oryctolagus cuniculus

UniProt ID:P11716 Pfam ID:PF08709, PF02815, PF01365, PF00622, PF02026, PF21119, PF08454, PF06459, PF00520

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Peptidyl-prolyl cis-trans iso
Gene (Uniprot):FKBP1B
Chain IDs:A (auth: E), B (auth: F), C (auth: G), D (auth: H)
Chain Length:107
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P68106 Pfam ID:PF00254 EC:5.2.1.8

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Calmodulin-1
Gene (Uniprot):CALM1
Chain IDs:E (auth: I), F (auth: J), G (auth: K), H (auth: L)
Chain Length:148
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P0DP23 Pfam ID:PF13499

Ligand Molecules
