ISDA: 9Z51

Deposition Date 2025-11-11

Release Date 2026-09-16

Last Version Date 2026-09-16

Entry Detail

PDB ID:

9Z51

Keywords:

IMMUNE SYSTEM

Title:

HPV_Jin TCR in complex with HLA-A*02:01 presenting HPV16 E7 9mer peptide (11-YMLDLQPET-19)

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
Human papillomavirus 16 (Taxon ID: 333760)

Expression System(s):

Escherichia coli, Homo sapiens

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

3.13 Å

R-Value Free:

0.26

R-Value Work:

0.22

R-Value Observed:

0.22

Space Group:

P 21 21 21

Download Validation Report

Macromolecular Entities

Polymer Type:polypeptide(L)
Molecule:HPV_Jin TCR alpha chain (TRAV
Chain IDs:C (auth: A), H (auth: E), M (auth: J), R (auth: Q)
Chain Length:0
Number of Molecules:4
Biological Source:Homo sapiens

Polymer Type:polypeptide(L)
Molecule:HPV_Jin TCR beta chain (TRBV5
Chain IDs:D (auth: B), I (auth: F), N (auth: K), S (auth: R)
Chain Length:0
Number of Molecules:4
Biological Source:Homo sapiens

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:MHC class I antigen
Gene (Uniprot):HLA-A
Chain IDs:A (auth: C), F (auth: G), K (auth: L), P (auth: S)
Chain Length:0
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:Q8WLS4

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Beta-2-microglobulin
Gene (Uniprot):B2M
Chain IDs:B (auth: D), G (auth: H), L (auth: M), Q (auth: T)
Chain Length:0
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P61769 Pfam ID:PF07654

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Protein E7
Gene (Uniprot):E7
Chain IDs:E (auth: P), J (auth: I), O (auth: N), T (auth: U)
Chain Length:0
Number of Molecules:4
Biological Source:Human papillomavirus 16

UniProt ID:P03129

Ligand Molecules
