ISDA: 9WV2

Deposition Date 2025-09-19

Release Date 2026-08-05

Last Version Date 2026-08-05

Entry Detail

PDB ID:

9WV2

Keywords:

TRANSLOCASE

Title:

Human TOM complex with substrate GGC1-sfGFP

Biological Source:

Source Organism(s):

Saccharomyces cerevisiae (strain ATCC 204508 / S288c) (Taxon ID: 559292)
Homo sapiens (Taxon ID: 9606)

Expression System(s):

Homo sapiens

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.15 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import receptor
Gene (Uniprot):TOMM5
Chain IDs:A, B
Chain Length:51
Number of Molecules:2
Biological Source:Homo sapiens

UniProt ID:Q8N4H5 Pfam ID:PF10642

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import receptor
Gene (Uniprot):TOMM6
Chain IDs:C, D
Chain Length:74
Number of Molecules:2
Biological Source:Homo sapiens

UniProt ID:Q96B49 Pfam ID:PF15184

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import receptor
Gene (Uniprot):TOMM7
Chain IDs:E, F
Chain Length:55
Number of Molecules:2
Biological Source:Homo sapiens

UniProt ID:Q9P0U1 Pfam ID:PF08038

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import receptor
Gene (Uniprot):TOMM22
Chain IDs:G, H
Chain Length:142
Number of Molecules:2
Biological Source:Homo sapiens

UniProt ID:Q9NS69 Pfam ID:PF04281

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import receptor
Gene (Uniprot):TOMM40
Chain IDs:I, J
Chain Length:361
Number of Molecules:2
Biological Source:Homo sapiens

UniProt ID:O96008 Pfam ID:PF01459

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial GTP/GDP carrier
Gene (Uniprot):GGC1
Mutagens:C222S
Chain IDs:K
Chain Length:300
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae (strain ATCC 204508 / S288c)

UniProt ID:P38988 Pfam ID:PF00153

Ligand Molecules
