9W48 image
Deposition Date 2025-07-31
Release Date 2026-08-05
Last Version Date 2026-08-05
Entry Detail
PDB ID:
9W48
Keywords:
HYDROLASE
Title:
Crystal structure of MacroD from Deinococcus radiodurans in complex with ADP-ribose
Biological Source:
Source Organism(s):
Deinococcus radiodurans R1 = ATCC 13939 = DSM 20539 (Taxon ID: 243230)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.64 Å
R-Value Free:
0.20
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
P 21 21 21
9W48 validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Macro domain-containing prote
Gene (Uniprot):DR_2288
Chain IDs:A, B
Chain Length:172
Number of Molecules:2
Biological Source:Deinococcus radiodurans R1 = ATCC 13939 = DSM 20539
UniProt ID:Q9RS39 Pfam ID:PF01661
Ligand Molecules
APR
AR6
Primary Citation
Structural and Biochemical Elucidation of DrMacroD
To Be Published ? ? ? (?)
Primary Citation of related structures
9W48
