9UPC image
Deposition Date 2025-04-28
Release Date 2026-02-11
Last Version Date 2026-02-11
Entry Detail
PDB ID:
9UPC
Keywords:
GENE REGULATION
Title:
Structure of human TREX-2
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.14 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9UPC validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Germinal-center associated nu
Gene (Uniprot):MCM3AP
Chain IDs:A
Chain Length:463
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:O60318 Pfam ID:PF03399
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCI domain-containing protein
Gene (Uniprot):PCID2
Chain IDs:B
Chain Length:426
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q5JVF3 Pfam ID:PF01399
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:26S proteasome complex subuni
Gene (Uniprot):SEM1
Chain IDs:C
Chain Length:70
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P60896 Pfam ID:PF05160
Ligand Molecules
NA
Primary Citation
Structure of human TREX-2
To Be Published ? ? ? (?)
Primary Citation of related structures
9UPB
