ISDA: 9TPA

Deposition Date 2025-12-17

Release Date 2026-07-01

Last Version Date 2026-07-01

Entry Detail

PDB ID:

9TPA

Keywords:

HYDROLASE

Title:

The ERAD misfolded glycoprotein checkpoint complex from Chaetomium thermophilum (EDEM:PDI heterodimer).

Biological Source:

Source Organism(s):

Aequorea victoria (Taxon ID: 6100)
Thermochaetoides thermophila (Taxon ID: 209285)

Expression System(s):

Homo sapiens

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.60 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Green fluorescent protein,alp
Gene (Uniprot):CTHT_0058730, GFP
Chain IDs:A
Chain Length:1284
Number of Molecules:1
Biological Source:Aequorea victoria, Thermochaetoides thermophila

UniProt ID:P42212,G0SCX7 Pfam ID:PF01532 EC:3.2.1.-

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Protein disulfide-isomerase
Gene (Uniprot):CTHT_0067360
Mutagens:Deletion of C-terminal ER retention signal
Chain IDs:B
Chain Length:507
Number of Molecules:1
Biological Source:Thermochaetoides thermophila

UniProt ID:G0SGS2 Pfam ID:PF00085, PF13848 EC:5.3.4.1

Ligand Molecules
