9TIW image
Deposition Date 2025-12-05
Release Date 2026-05-20
Last Version Date 2026-07-08
Entry Detail
PDB ID:
9TIW
Keywords:
VIRUS
Title:
Phage 812 baseplate in the post-contraction state - composite
Biological Source:
Source Organism(s):
Staphylococcus phage 812K1/420 (Taxon ID: 3434241)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
4.40 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9TIW validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF61
Gene (Uniprot):PhageK_114
Chain IDs:A
Chain Length:142
Number of Molecules:1
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q6
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF62
Gene (Uniprot):PhageK_115
Chain IDs:B, C
Chain Length:142
Number of Molecules:2
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q5
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF63
Gene (Uniprot):PhageK_116
Chain IDs:D
Chain Length:1019
Number of Molecules:1
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q4
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF64
Gene (Uniprot):PhageK_117
Chain IDs:E, F, G, H, I, J
Chain Length:173
Number of Molecules:6
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q3
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF65
Gene (Uniprot):PhageK_118
Chain IDs:K, L, M, N, O, P
Chain Length:1152
Number of Molecules:6
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q2
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF68
Gene (Uniprot):PhageK_122
Chain IDs:Q, R, S
Chain Length:458
Number of Molecules:3
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7P9
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF49
Gene (Uniprot):PhageK_100
Chain IDs:T, U, V, W, X, Y
Chain Length:587
Number of Molecules:6
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7R8
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF50
Gene (Uniprot):PhageK_101
Chain IDs:Z, AA (auth: a), BA (auth: b), CA (auth: c), DA (auth: d), EA (auth: e), FA (auth: f), GA (auth: g), HA (auth: h), IA (auth: i), JA (auth: j), KA (auth: k), LA (auth: l), MA (auth: m), NA (auth: n)
Chain Length:1152
Number of Molecules:15
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7R7
Ligand Molecules
NA
Primary Citation
Conformational changes of the baseplate regulating tail contraction of Staphylococcus phage 812.
Embo J. ? ? ? (2026)
PMID: 42350675 DOI: 10.1038/s44318-026-00834-9
Primary Citation of related structures
9TIW
