9TIO image
Deposition Date 2025-12-05
Release Date 2026-05-20
Last Version Date 2026-07-08
Entry Detail
PDB ID:
9TIO
Keywords:
VIRUS
Title:
Phage 812 baseplate in the pre-contraction state - upper arm (segment B)
Biological Source:
Source Organism(s):
Staphylococcus phage 812K1/420 (Taxon ID: 3434241)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.90 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9TIO validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF65
Gene (Uniprot):PhageK_118
Chain IDs:A, B, D
Chain Length:1152
Number of Molecules:3
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q2
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF64
Gene (Uniprot):PhageK_117
Chain IDs:C, E, F, K
Chain Length:173
Number of Molecules:4
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q3
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ORF63
Gene (Uniprot):PhageK_116
Chain IDs:G
Chain Length:1019
Number of Molecules:1
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:Q6Y7Q4
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CBM-cenC domain-containing pr
Gene (Uniprot):812a_125, 812F1_125, K1/420_125, K1_125
Chain IDs:H, I, J
Chain Length:640
Number of Molecules:3
Biological Source:Staphylococcus phage 812K1/420
UniProt ID:A0A0U1UXW5
Ligand Molecules
NA
Primary Citation
Conformational changes of the baseplate regulating tail contraction of Staphylococcus phage 812.
Embo J. ? ? ? (2026)
PMID: 42350675 DOI: 10.1038/s44318-026-00834-9
Primary Citation of related structures
9TIO
