ISDA: 9TF0

Deposition Date 2025-11-26

Release Date 2026-06-24

Last Version Date 2026-06-24

Entry Detail

PDB ID:

9TF0

Keywords:

VIRUS

Title:

Structure of echovirus 18 in complex with neonatal Fc receptor

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
Echovirus E18 (Taxon ID: 47506)

Expression System(s):

Spodoptera frugiperda

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.26 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Echovirus 18 viral protein 1
Chain IDs:C (auth: A)
Chain Length:287
Number of Molecules:1
Biological Source:Echovirus E18

UniProt ID:Q8V635 EC:3.4.22.29,3.6.1.15,3.4.22.28,2.7.7.48

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Echovirus 18 viral protein 2
Chain IDs:D (auth: B)
Chain Length:260
Number of Molecules:1
Biological Source:Echovirus E18

UniProt ID:Q8V635 EC:3.4.22.29,3.6.1.15,3.4.22.28,2.7.7.48

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Echovirus 18 viral protein 3
Chain IDs:A (auth: C)
Chain Length:239
Number of Molecules:1
Biological Source:Echovirus E18

UniProt ID:Q8V635 EC:3.4.22.29,3.6.1.15,3.4.22.28,2.7.7.48

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Echovirus 18 viral protein 4
Chain IDs:B (auth: D)
Chain Length:68
Number of Molecules:1
Biological Source:Echovirus E18

UniProt ID:Q8V635 EC:3.4.22.29,3.6.1.15,3.4.22.28,2.7.7.48

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:IgG receptor FcRn large subun
Gene (Uniprot):FCGRT
Chain IDs:E (auth: G)
Chain Length:267
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P55899 Pfam ID:PF00129, PF07654

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Beta-2-microglobulin
Gene (Uniprot):B2M
Chain IDs:F (auth: H)
Chain Length:99
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P61769 Pfam ID:PF07654

Ligand Molecules

PLM

Primary Citation

Particles of echovirus 18 open to release their genomes in vivo

Mukhamedova, L, Plevka, P, Buchta, D, Fuzik, T, Trebichalska, Z, Novacek, J, Levdansky, Y, Moravcova, J, Hrebik, D, Tollefsrud, T.G, Andersen, J.T.Show

To Be Published ? ? ? (?)
