Deposition Date 2021-03-26
Release Date 2022-04-13
Last Version Date 2023-11-01
Entry Detail
PDB ID:
7O0I
Keywords:
SIGNALING PROTEIN
Title:
Vibrio vulnificus stressosome
Biological Source:
Source Organism(s):
Vibrio vulnificus (Taxon ID: 672)
Expression System(s):
Vibrio vulnificus
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
8.30 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
7O0I validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Anti-anti-sigma factor
Gene (Uniprot):CRN52_18810, FORC53_3527
Chain IDs:B, N (auth: C), O (auth: E), P (auth: F), Q (auth: G), R (auth: H), S (auth: I), T (auth: J), U (auth: K), V (auth: L), W (auth: M), X (auth: N), Y (auth: Q), Z (auth: R), AA (auth: S), BA (auth: T), CA (auth: U), DA (auth: V), EA (auth: W), FA (auth: X), GA (auth: Y), HA (auth: Z), IA (auth: c), JA (auth: d), KA (auth: h), LA (auth: i), MA (auth: j), NA (auth: k), OA (auth: l), PA (auth: m), QA (auth: n), RA (auth: o), SA (auth: p), TA (auth: q), UA (auth: r), VA (auth: s), WA (auth: w), XA (auth: x), YA (auth: y), ZA (auth: z), AB (auth: 1), BB (auth: 2), CB (auth: 4), DB (auth: 5), EB (auth: 6), FB (auth: 7), GB (auth: 8), HB (auth: 9)
Chain Length:306
Number of Molecules:48
Biological Source:Vibrio vulnificus
UniProt ID:A0A1W6M9Q5 Pfam ID:PF11563, PF01740
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:RsbS, negative regulator of s
Gene (Uniprot):CRN52_18815
Chain IDs:A (auth: a), C (auth: b), D (auth: A), E (auth: D), F (auth: O), G (auth: P), H (auth: e), I (auth: f), J (auth: g), K (auth: t), L (auth: u), M (auth: v)
Chain Length:115
Number of Molecules:12
Biological Source:Vibrio vulnificus
UniProt ID:A0A2S3QZH9 Pfam ID:PF01740
Ligand Molecules
NA
Primary Citation
The Vibrio vulnificus stressosome is an oxygen-sensor involved in regulating iron metabolism
Commun Biol ? ? ? (2022)
DOI: 10.1038/s42003-022-03548-w
