ISDA: 3KTU

Deposition Date 2009-11-26

Release Date 2010-07-14

Last Version Date 2023-09-06

Entry Detail

PDB ID:

3KTU

Keywords:

HYDROLASE, LYASE/DNA

Title:

Structure of human 8-oxoGuanine Glycosylase 1 bound to fluorninated oxoG-containing DNA

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
synthetic construct (Taxon ID: 32630)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

2.30 Å

R-Value Free:

0.25

R-Value Work:

0.22

R-Value Observed:

0.22

Space Group:

P 65 2 2

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:N-glycosylase/DNA lyase
Gene (Uniprot):OGG1
Chain IDs:A
Chain Length:317
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:O15527 Pfam ID:PF07934, PF00730 EC:3.2.2.23

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*GP*GP*TP*AP*GP*AP*
Chain IDs:B
Chain Length:13
Number of Molecules:1
Biological Source:synthetic construct

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*GP*TP*CP*CP*AP*(FD
Chain IDs:C
Chain Length:12
Number of Molecules:1
Biological Source:synthetic construct

Modified Residue
