Deposition Date 2009-10-19
Release Date 2009-10-27
Last Version Date 2024-11-20
Entry Detail
PDB ID:
3KAT
Keywords:
APOPTOSIS
Title:
Crystal Structure of the CARD domain of the human NLRP1 protein, Northeast Structural Genomics Consortium Target HR3486E
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli bl21(de3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
3.10 Å
R-Value Free:
0.26
R-Value Work:
0.20
Space Group:
P 41 21 2
3KAT validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:NACHT, LRR and PYD domains-co
Gene (Uniprot):NLRP1
Chain IDs:A
Chain Length:107
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q9C000 Pfam ID:PF00619
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
NA
Primary Citation
Northeast Structural Genomics Consortium Target HR3486E
To be published ? ? ? (?)
Primary Citation of related structures
3KAT
