Deposition Date 2026-03-18
Release Date 2026-04-22
Last Version Date 2026-04-22
Entry Detail
PDB ID:
11YV
Keywords:
OXIDOREDUCTASE
Title:
Structure of Bacillus subtilis Nitric Oxide Synthase in complex with 7-((3-(((3-(6-aminopyridin-2-yl)propyl)amino)methyl)phenoxy)methyl)quinolin-2-amine
Biological Source:
Source Organism(s):
Bacillus subtilis subsp. subtilis str. 168 (Taxon ID: 224308)
Expression System(s):
Escherichia coli bl21(de3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.86 Å
R-Value Free:
0.19
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
P 21 21 2
11YV validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Nitric oxide synthase oxygena
Gene (Uniprot):nos
Mutagens:E25A, E26A, E316A
Chain IDs:A
Chain Length:363
Number of Molecules:1
Biological Source:Bacillus subtilis subsp. subtilis str. 168
UniProt ID:O34453 Pfam ID:PF02898 EC:1.14.13.39
Ligand Molecules
CL
GOL
HEM
PEG
POL
V5D
Primary Citation
Anti-MRSA inhibitors targeting bacterial nitric oxide synthase
To be published ? ? ? (?)
Primary Citation of related structures
6XK4
