ISDA: 9ZWY

Deposition Date 2026-01-03

Release Date 2026-09-23

Last Version Date 2026-09-23

Entry Detail

PDB ID:

9ZWY

Keywords:

TRANSFERASE

Title:

Crystal structure of the N4BP2 polynucleotide kinase domain complexed with ATP, Mg, and the trinucleotide substrate CUA.

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
synthetic construct (Taxon ID: 32630)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

2.10 Å

R-Value Free:

0.23

R-Value Work:

0.20

R-Value Observed:

0.20

Space Group:

I 2 2 2

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:NEDD4-binding protein 2
Gene (Uniprot):N4BP2
Chain IDs:A, B, C
Chain Length:0
Number of Molecules:3
Biological Source:Homo sapiens

UniProt ID:Q86UW6 Pfam ID:PF13671 EC:3.-.-.-

Polymer Type:polyribonucleotide
Molecule:5'-OH RNA (5'-r(CpUpA)-3')
Chain IDs:D, E, F
Chain Length:0
Number of Molecules:3
Biological Source:synthetic construct

Ligand Molecules
