9ZMA image
Deposition Date 2025-12-09
Release Date 2026-05-27
Last Version Date 2026-05-27
Entry Detail
PDB ID:
9ZMA
Keywords:
IMMUNE SYSTEM
Title:
Crystal structure of Fab 7160 in complex with major repeat region (NANP6)from circumsporozoite protein
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Plasmodium falciparum 3D7 (Taxon ID: 36329)
Expression System(s):
Cricetulus griseus, Synthetic construct
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.33 Å
R-Value Free:
0.23
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 1 21 1
9ZMA validation report missing
Macromolecular Entities
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Heavy Chain of Fab 7160
Chain IDs:A, C, E, G
Chain Length:230
Number of Molecules:4
Biological Source:Homo sapiens
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Light Chain of Fab 7160
Chain IDs:B, D, F, H
Chain Length:219
Number of Molecules:4
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Circumsporozoite protein
Gene (Uniprot):CSP
Chain IDs:I, J
Chain Length:24
Number of Molecules:2
Biological Source:Plasmodium falciparum 3D7
UniProt ID:Q7K740
Primary Citation
Structural basis for conserved and distinct antigen recognition by a lineage of malaria-protective antibodies
Plos Pathog. ? ? ? (2026)
Primary Citation of related structures
9ZMA
