9ZM8 image
Deposition Date 2025-12-09
Release Date 2026-05-27
Last Version Date 2026-05-27
Entry Detail
PDB ID:
9ZM8
Keywords:
IMMUNE SYSTEM
Title:
Crystal structure of 7160 in complex with minor repeat region from circumsporozoite protein
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Plasmodium falciparum 3D7 (Taxon ID: 36329)
Expression System(s):
Cricetulus griseus, Synthetic construct
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.27 Å
R-Value Free:
0.28
R-Value Work:
0.25
R-Value Observed:
0.25
Space Group:
P 21 21 21
9ZM8 validation report missing
Macromolecular Entities
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Heavy Chain of Fab 7160
Chain IDs:A, F (auth: H)
Chain Length:230
Number of Molecules:2
Biological Source:Homo sapiens
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ligh Chain of Fab 7160
Chain IDs:B, E (auth: G)
Chain Length:219
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Circumsporozoite protein
Gene (Uniprot):CSP
Chain IDs:C, D
Chain Length:20
Number of Molecules:2
Biological Source:Plasmodium falciparum 3D7
UniProt ID:Q7K740
Primary Citation
Structural basis for conserved and distinct antigen recognition by a lineage of malaria-protective antibodies
Plos Pathog. ? ? ? (2026)
Primary Citation of related structures
9ZM8
