9ZB4 image
Deposition Date 2025-11-20
Release Date 2026-10-07
Last Version Date 2026-10-14
Entry Detail
PDB ID:
9ZB4
Title:
Cryo-EM structure of Leishmania tarentolae respiratory complex V (ATP synthase) membrane region
Biological Source:
Source Organism(s):
Method Details:
Experimental Method:
Resolution:
3.73 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_0809900, LtaPh_0810161
Chain IDs:V (auth: a), GA (auth: A)
Chain Length:99
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_0309100
Chain IDs:M (auth: b), Z (auth: B)
Chain Length:102
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2117900
Chain IDs:N (auth: d), SA (auth: D)
Chain Length:384
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2516900
Chain IDs:Q (auth: e), CA (auth: E)
Chain Length:123
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2522100
Chain IDs:W (auth: f), HA (auth: F)
Chain Length:136
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2610300
Chain IDs:U (auth: g), TA (auth: G)
Chain Length:104
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2706600
Chain IDs:O (auth: h), AA (auth: H)
Chain Length:163
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_3330400
Chain IDs:P (auth: i), BA (auth: I)
Chain Length:127
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_3410600
Chain IDs:R (auth: j), DA (auth: J)
Chain Length:66
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_3439800
Chain IDs:S (auth: k), EA (auth: K)
Chain Length:75
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:ATPase 6
Gene (Uniprot):MURF4
Chain IDs:L (auth: l), Y (auth: L)
Chain Length:231
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2506200
Chain IDs:T (auth: m), FA (auth: M)
Chain Length:59
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Gene (Uniprot):LtaPh_2216100
Chain IDs:X (auth: n), UA (auth: N)
Chain Length:78
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:LtaP27_632926_633111, LtATPEG
Chain IDs:A (auth: o), VA (auth: O)
Chain Length:55
Number of Molecules:2
Biological Source:Leishmania tarentolae
Polymer Type:polypeptide(L)
Molecule:Mitochondrial ATP synthase su
Chain IDs:B (auth: x), C (auth: c), D (auth: p), E (auth: q), F (auth: r), G (auth: s), H (auth: y), I (auth: u), J (auth: v), K (auth: w), IA (auth: X), JA (auth: C), KA (auth: P), LA (auth: Q), MA (auth: R), NA (auth: S), OA (auth: Y), PA (auth: U), QA (auth: V), RA (auth: W)
Chain Length:76
Number of Molecules:20
Biological Source:Leishmania tarentolae
Ligand Molecules
Primary Citation
Conserved and divergent mitochondrial assemblies in kinetoplastid parasites.
Mol.Cell 86 4043 ? (2026)
PMID: 42822418 DOI: 10.1016/j.molcel.2026.08.031

Abstact

The mitochondrial proteomes of Leishmania tarentolae and Trypanosoma brucei contain approximately 1,700 proteins, most of which lack homologs in higher eukaryotes. Here, we integrate complexome profiling and cryo-electron microscopy to define conserved and lineage-specific macromolecular assemblies that support mitochondrial functions in these kinetoplastid protozoa. Comparative analyses reveal species- and life-stage-dependent differences in the abundance and composition of respiratory, metabolic, RNA processing, and other complexes, refining and expanding current annotations. Structures of L. tarentolae respiratory complex III(2) (CIII(2)), complex IV(2) (CIV(2)), and complex V (CV) identify nine previously unrecognized nuclear-encoded subunits and resolve five mitochondrially encoded proteins, including products of pan-edited mRNAs. These reconstructions uncover architectural innovations: a subunit 8 of ubiquinol cytochrome-c reductase (QCR8) N-terminal extension that plugs the vestigial mitochondrial processing peptidase (MPP)alpha/beta cavity in CIII(2), a CIV(2) dimer stabilized by an extensive clade-restricted interface, and a CV dimer containing the mitochondrially encoded ATP6 subunit. Together, our findings reveal how kinetoplastids assemble specialized mitochondrial machinery while incorporating diverged components into core modules shared across eukaryotes.
