9YLN image
Deposition Date 2025-10-08
Release Date 2026-03-04
Last Version Date 2026-03-25
Entry Detail
PDB ID:
9YLN
Title:
BCL11A ZF4-6 in Complex with a DNA Sequence Observed in the Human Globin Locus Containing Motif TGGCCA (12-mer)
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.15 Å
R-Value Free:
0.24
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 41 21 2
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:B-cell lymphoma/leukemia 11A
Gene (Uniprot):BCL11A
Chain IDs:A
Chain Length:108
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polydeoxyribonucleotide
Molecule:DNA Strand II
Chain IDs:B (auth: E)
Chain Length:13
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polydeoxyribonucleotide
Molecule:DNA Strand I
Chain IDs:C (auth: F)
Chain Length:13
Number of Molecules:1
Biological Source:Homo sapiens
Primary Citation
Regulation of BCL11A DNA binding and expression in human erythrocyte precursor HUDEP-2 cells.
Biorxiv ? ? ? (2026)
PMID: 41822826 DOI: 10.64898/2026.02.06.704516

Abstact

BCL11A is a transcription factor crucial for neurodevelopment and hematopoiesis. It regulates the developmental switch from fetal hemoglobin (HbF) to adult hemoglobin and is a major therapeutic target for sickle cell disease and beta-thalassemia. BCL11A exists in multiple isoforms, including the L isoform (containing a single two-finger ZF2-3 DNA-binding domain) and the XL isoform (containing two arrays: the two-finger ZF2-3 and the three-finger ZF4-6). We used three approaches to investigate BCL11A functions. First, we examined DNA recognition by BCL11A, which preferentially binds the short 6-bp DNA motif TGnCCA. ZF4-6 recognizes all four variants of this motif with distinct strand-specific interactions: TGtCCA on the top strand, TG(A/C)CCA on the complementary strand, and the palindromic TGgCCA on either strand. ZF2-3 also binds TGtCCA from the top strand, featuring a unique thymine interaction by ZF2 Phe388. Motif multiplicity within BCL11A binding sites may promote BCL11A oligomerization by enabling multiple ZF arrays to engage DNA simultaneously. Second, we treated HUDEP-2 cells (which express adult hemoglobin) with inhibitors targeting three epigenetic silencing marks - DNA methylation, histone H3 lysine 9 methylation or H3 lysine 27 methylation. All treatments, individually or in combination, increased HbF expression to varying degrees. Notably, FTX6058 markedly reduced BCL11A transcription and translation (likely via effects on LIN28B), while EML741 caused a partial reduction. Third, we screened 213 pomalidomide- and lenalidomide-derived compounds and quantified proportions of HbF+ cells by flow cytometry. Effects of four compounds were analyzed by protein mass spectrometry. Although BCL11A levels themselves were unchanged, all four compounds selectively decreased levels of known pomalidomide targets, with consistently decreased levels of the zinc-finger proteins IKZF1 and ZFP91. Together, our studies clarify how BCL11A recognizes DNA, how its expression can be modulated epigenetically, and how small-molecule degraders influence its regulatory network, providing new avenues for HbF reactivation therapies.
