9YJS image
Deposition Date 2025-10-03
Release Date 2026-07-01
Last Version Date 2026-07-01
Entry Detail
PDB ID:
9YJS
Title:
Crystal structure of anti-HCV human broad neutralizing antibody B098
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.78 Å
R-Value Free:
0.27
R-Value Work:
0.23
R-Value Observed:
0.23
Space Group:
P 32 2 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:K400 fab heavy chain
Chain IDs:A (auth: H)
Chain Length:234
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:K400 fab light chain
Chain IDs:B (auth: L)
Chain Length:217
Number of Molecules:1
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
The conserved bridging domain on HCV E1E2 glycoprotein complex is targeted by neutralizing antibodies from diverse lineages.
Biorxiv ? ? ? (2025)
PMID: 41280117 DOI: 10.1101/2025.11.05.686883

Abstact

The induction of potent and cross-reactive neutralizing antibody (nAb) responses remains a challenge in vaccine development against antigenically diverse viruses such as hepatitis C virus (HCV). The HCV E1E2 glycoprotein complex contains two major neutralizing sites: the neutralizing face (NF) and the less explored bridging domain (BD). Here, we characterized 25 BD-targeting nAbs isolated from infection or immunization. These antibodies arise from diverse B cell lineages but share convergent CDRH3 features. Epitope mapping by alanine scanning and negative-stain electron microscopy revealed overlapping epitopes on BD spanning antigenic regions AR4 and AR5, with variable back layer engagement. The crystal structure of a non-human primate BD nAb RM3-26 in complex with E2 uncovered a back layer-directed recognition mode analogous to that of the human nAb hcab40. Together, BD- and NF-directed nAbs exhibited additivity in their neutralization, highlighting BD as a conserved site of vulnerability on HCV and a valuable target for rational vaccine design.
