ISDA: 9YEE

Deposition Date 2025-09-24

Release Date 2026-06-10

Last Version Date 2026-06-10

Entry Detail

PDB ID:

9YEE

Keywords:

MOTOR PROTEIN

Title:

Rod-hook protein in Vibrio cholerae at assembled, opened state

Biological Source:

Source Organism(s):

Vibrio cholerae O1 biovar El Tor str. N16961 (Taxon ID: 243277)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.44 Å

Aggregation State:

CELL

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellar basal-body rod prot
Gene (Uniprot):VC_2195
Chain IDs:A (auth: Ba), B (auth: Bb), C (auth: Bc), D (auth: Bd), E (auth: Be), F (auth: Bf), G (auth: Bg), H (auth: Bh), I (auth: Bi), J (auth: Bj), K (auth: Bk), L (auth: Bl), M (auth: Bm), N (auth: Bn), O (auth: Bo), P (auth: Bp), Q (auth: Bq), R (auth: Br), S (auth: Bs), T (auth: Bt), U (auth: Bu), V (auth: Bv), W (auth: Bw), X (auth: Bx), Y (auth: By), Z (auth: Bz), BA (auth: Cb)
Chain Length:262
Number of Molecules:27
Biological Source:Vibrio cholerae O1 biovar El Tor str. N16961

UniProt ID:Q9KQ12 Pfam ID:PF00460, PF22692, PF06429

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellar basal-body rod prot
Gene (Uniprot):VC_2196
Chain IDs:AA (auth: Ca), CA (auth: Cc), DA (auth: Cd), VA (auth: Cv), WA (auth: Cw)
Chain Length:249
Number of Molecules:5
Biological Source:Vibrio cholerae O1 biovar El Tor str. N16961

UniProt ID:Q9KQ11 Pfam ID:PF00460, PF22692, PF06429

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellar hook protein FlgE
Gene (Uniprot):VC_2197
Chain IDs:EA (auth: Ce), FA (auth: Cf), GA (auth: Cg), HA (auth: Ch), IA (auth: Ci), JA (auth: Cj), KA (auth: Ck), LA (auth: Cl), MA (auth: Cm), NA (auth: Cn), OA (auth: Co), PA (auth: Cp), QA (auth: Cq), RA (auth: Cr), SA (auth: Cs), TA (auth: Ct), UA (auth: Cu)
Chain Length:434
Number of Molecules:17
Biological Source:Vibrio cholerae O1 biovar El Tor str. N16961

UniProt ID:Q9KQ10 Pfam ID:PF00460, PF22692, PF07559, PF06429

Ligand Molecules

Primary Citation

In-situ cryo-EM structures reveal mechanisms of sheathed flagellar assembly, rotation, and disassembly in Vibrio cholerae

Wangbiao, G, Jian, Y, Jin, H.P, Fitnat, Y, Jun, L.Show

To Be Published ? ? ? (?)
