9YDS image
Deposition Date 2025-09-23
Release Date 2026-06-10
Last Version Date 2026-06-10
Entry Detail
PDB ID:
9YDS
Keywords:
MOTOR PROTEIN
Title:
H-ring subunit FlgO and FlgP in Vibrio cholerae at assembled, opened state
Biological Source:
Source Organism(s):
Vibrio cholerae O1 biovar El Tor str. N16961 (Taxon ID: 243277)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.45 Å
Aggregation State:
CELL
Reconstruction Method:
SINGLE PARTICLE
9YDS validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Lipoprotein
Gene (Uniprot):VC_2206
Chain IDs:A (auth: Aa), C (auth: Ac), E (auth: Ae), G (auth: Ag), I (auth: Ai), K (auth: Ak), M (auth: Am), O (auth: Ao), Q (auth: Aq), S (auth: As), U (auth: Au), W (auth: Aw), Y (auth: Ay), AA (auth: Ba), CA (auth: Bc), EA (auth: Be), GA (auth: Bg), IA (auth: Bi), KA (auth: Bk), MA (auth: Bm), OA (auth: Bo), QA (auth: Bq), SA (auth: Bs), UA (auth: Bu), WA (auth: Bw), YA (auth: By), AB (auth: Ca), CB (auth: Cc), EB (auth: Ce), GB (auth: Cg), IB (auth: Ci), KB (auth: Ck), MB (auth: Cm), OB (auth: Co), QB (auth: Cq), SB (auth: Cs), UB (auth: Cu), WB (auth: Cw), YB (auth: Cy), AC (auth: Da), CC (auth: Dc), EC (auth: De), GC (auth: Dg), IC (auth: Di), KC (auth: Dk), MC (auth: Dm), OC (auth: Do), QC (auth: Dq), SC (auth: Ds), UC (auth: Du), WC (auth: Dw), YC (auth: Dy), AD (auth: Ea), CD (auth: Ec), ED (auth: Ee), GD (auth: Eg), ID (auth: Ei), KD (auth: Ek)
Chain Length:104
Number of Molecules:58
Biological Source:Vibrio cholerae O1 biovar El Tor str. N16961
UniProt ID:Q9KQ01
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:FlgO domain-containing protei
Gene (Uniprot):VC_2207
Chain IDs:B (auth: Ab), D (auth: Ad), F (auth: Af), H (auth: Ah), J (auth: Aj), L (auth: Al), N (auth: An), P (auth: Ap), R (auth: Ar), T (auth: At), V (auth: Av), X (auth: Ax), Z (auth: Az), BA (auth: Bb), DA (auth: Bd), FA (auth: Bf), HA (auth: Bh), JA (auth: Bj), LA (auth: Bl), NA (auth: Bn), PA (auth: Bp), RA (auth: Br), TA (auth: Bt), VA (auth: Bv), XA (auth: Bx), ZA (auth: Bz), BB (auth: Cb), DB (auth: Cd), FB (auth: Cf), HB (auth: Ch), JB (auth: Cj), LB (auth: Cl), NB (auth: Cn), PB (auth: Cp), RB (auth: Cr), TB (auth: Ct), VB (auth: Cv), XB (auth: Cx), ZB (auth: Cz), BC (auth: Db), DC (auth: Dd), FC (auth: Df), HC (auth: Dh), JC (auth: Dj), LC (auth: Dl), NC (auth: Dn), PC (auth: Dp), RC (auth: Dr), TC (auth: Dt), VC (auth: Dv), XC (auth: Dx), ZC (auth: Dz), BD (auth: Eb), DD (auth: Ed), FD (auth: Ef), HD (auth: Eh), JD (auth: Ej), LD (auth: El)
Chain Length:192
Number of Molecules:58
Biological Source:Vibrio cholerae O1 biovar El Tor str. N16961
UniProt ID:Q9KQ00 Pfam ID:PF17680
Ligand Molecules
NA
Primary Citation
In-situ cryo-EM structures reveal mechanisms of sheathed flagellar assembly, rotation, and disassembly in Vibrio cholerae
To Be Published ? ? ? (?)
