9XGV image
Deposition Date 2025-10-31
Release Date 2026-06-24
Last Version Date 2026-07-22
Entry Detail
PDB ID:
9XGV
Keywords:
PROTEIN TRANSPORT
Title:
Colanic acid polysaccharide related protein structures
Biological Source:
Source Organism(s):
Escherichia coli (strain K12) (Taxon ID: 83333)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.25 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9XGV validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tyrosine-protein kinase wzc
Gene (Uniprot):wzc
Chain IDs:A, B, D, F, H, J, L, N
Chain Length:720
Number of Molecules:8
Biological Source:Escherichia coli (strain K12)
UniProt ID:P76387 Pfam ID:PF02706, PF23607, PF13807, PF13614 EC:2.7.10.1
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Putative polysaccharide expor
Gene (Uniprot):wza
Chain IDs:C, E, G, I, K, M, O, P
Chain Length:382
Number of Molecules:8
Biological Source:Escherichia coli (strain K12)
UniProt ID:P0A930 Pfam ID:PF02563, PF22461, PF18412
Ligand Molecules
NA
Primary Citation
Architecture of the Wza-Wzc complex that mediates colanic acid translocation across the cell envelope in Gram-negative bacteria.
Nat Commun ? ? ? (2026)
PMID: 42399268 DOI: 10.1038/s41467-026-75198-z
Primary Citation of related structures
9XGV
