9XFR image
Deposition Date 2025-10-29
Release Date 2026-05-27
Last Version Date 2026-05-27
Entry Detail
PDB ID:
9XFR
Keywords:
VIRAL PROTEIN
Title:
The crystal structure of SARS-CoV-2 Main protease in complex with inhibitor FD2-12
Biological Source:
Source Organism(s):
Severe acute respiratory syndrome coronavirus 2 (Taxon ID: 2697049)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.15 Å
R-Value Free:
0.25
R-Value Work:
0.20
R-Value Observed:
0.21
Space Group:
C 1 2 1
9XFR validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:3C-like proteinase nsp5
Gene (Uniprot):rep
Chain IDs:A
Chain Length:305
Number of Molecules:1
Biological Source:Severe acute respiratory syndrome coronavirus 2
UniProt ID:P0DTD1 Pfam ID:PF05409 EC:2.7.7.48
Ligand Molecules
A1EZ6
Primary Citation
The crystal structure of SARS-CoV-2 Main protease in complex with inhibitor FD2-12
To Be Published ? ? ? (?)
Primary Citation of related structures
9XFR
