ISDA: 9X9Z

Deposition Date 2025-10-22

Release Date 2026-08-05

Last Version Date 2026-08-05

Entry Detail

PDB ID:

9X9Z

Keywords:

IMMUNE SYSTEM

Title:

Structure of the Omicron BA.2.86 variant Spike N-terminal domain(NTD)in complex with the antibody Fab fragment, C1717

Biological Source:

Source Organism(s):

Severe acute respiratory syndrome coronavirus 2 (Taxon ID: 2697049)
Homo sapiens (Taxon ID: 9606)

Expression System(s):

Homo sapiens

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

2.55 Å

R-Value Free:

0.24

R-Value Work:

0.19

R-Value Observed:

0.19

Space Group:

P 1 21 1

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Spike protein S1
Gene (Uniprot):S
Chain IDs:A
Chain Length:295
Number of Molecules:1
Biological Source:Severe acute respiratory syndrome coronavirus 2

UniProt ID:P0DTC2 Pfam ID:PF16451

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:C1717 heavy chain
Chain IDs:B (auth: H)
Chain Length:233
Number of Molecules:1
Biological Source:Homo sapiens

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:C1717 light chain
Chain IDs:C (auth: L)
Chain Length:216
Number of Molecules:1
Biological Source:Homo sapiens

Ligand Molecules

NAG

Primary Citation

Structure of the Omicron BA.2.86 variant Spike N-terminal domain(NTD)in complex with the antibody Fab fragment, C1717

Zhou, J.J, Gao, G.F.Show

To Be Published ? ? ? (?)
