ISDA: 9WV1

Deposition Date 2025-09-19

Release Date 2026-08-05

Last Version Date 2026-08-05

Entry Detail

PDB ID:

9WV1

Keywords:

TRANSLOCASE

Title:

Human TIM22 complex wtih substrate GGC1-sfGFP

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)

Expression System(s):

Homo sapiens

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.10 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import inner me
Gene (Uniprot):TIMM22
Chain IDs:A
Chain Length:217
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:Q9Y584 Pfam ID:PF02466

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Acylglycerol kinase, mitochon
Gene (Uniprot):AGK
Chain IDs:B
Chain Length:422
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:Q53H12 Pfam ID:PF00781, PF19712 EC:2.7.1.94

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import inner me
Gene (Uniprot):TIMM29
Chain IDs:C
Chain Length:260
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:Q9BSF4 Pfam ID:PF10171

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import inner me
Gene (Uniprot):TIMM9
Chain IDs:D, E, F, K, L
Chain Length:89
Number of Molecules:5
Biological Source:Homo sapiens

UniProt ID:Q9Y5J7 Pfam ID:PF02953

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import inner me
Gene (Uniprot):TIMM10
Chain IDs:G, H, I, M, N, O
Chain Length:90
Number of Molecules:6
Biological Source:Homo sapiens

UniProt ID:P62072 Pfam ID:PF02953

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Mitochondrial import inner me
Gene (Uniprot):TIMM10B
Chain IDs:J
Chain Length:103
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:Q9Y5J6 Pfam ID:PF02953

Ligand Molecules
