9WMF image
Deposition Date 2025-09-03
Release Date 2026-05-13
Last Version Date 2026-05-13
Entry Detail
PDB ID:
9WMF
Keywords:
RNA BINDING PROTEIN/DNA
Title:
Cryo-EM strucutre of MbpAgo-gDNA complex
Biological Source:
Source Organism(s):
Mucilaginibacter paludis DSM 18603 (Taxon ID: 714943)
synthetic construct (Taxon ID: 32630)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.57 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9WMF validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Piwi domain-containing protei
Gene (Uniprot):Mucpa_0938
Chain IDs:A, C (auth: B)
Chain Length:811
Number of Molecules:2
Biological Source:Mucilaginibacter paludis DSM 18603
UniProt ID:H1YCU5
Polymer Type:polydeoxyribonucleotide
Molecule:guide DNA (5'-D(P*T)-R(P*GP*A
Chain IDs:B (auth: C), D
Chain Length:18
Number of Molecules:2
Biological Source:synthetic construct
Ligand Molecules
NA
Primary Citation
Structural and mechanistic insights into MbpAgo
To Be Published ? ? ? (?)
Primary Citation of related structures
9WMF
