Deposition Date 2025-08-15
Release Date 2026-07-15
Last Version Date 2026-07-15
Entry Detail
PDB ID:
9WC2
Keywords:
IMMUNE SYSTEM
Title:
Crystal structure of HLA-A*02:01-WT1 complexed with C4 TCR
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.25 Å
R-Value Free:
0.23
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
P 21 21 21
9WC2 validation report missing
Macromolecular Entities
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:C4 TCR alpha chain
Chain IDs:A
Chain Length:201
Number of Molecules:1
Biological Source:Homo sapiens
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:C4 TCR beta chain
Chain IDs:B
Chain Length:241
Number of Molecules:1
Biological Source:Homo sapiens
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:HLA-A*02:01
Chain IDs:C
Chain Length:273
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Beta-2-microglobulin
Gene (Uniprot):B2M
Chain IDs:D
Chain Length:100
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61769 Pfam ID:PF07654
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Wilms tumor protein
Gene (Uniprot):WT1
Chain IDs:E
Chain Length:9
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P19544
Primary Citation
Molecular mechanism of natural T cell receptor recognition of WT1 antigen with implications for epitope fidelity and immunotherapy design
To Be Published ? ? ? (?)
