ISDA: 9W71

Deposition Date 2025-08-05

Release Date 2026-08-12

Last Version Date 2026-08-12

Entry Detail

PDB ID:

9W71

Keywords:

GENE REGULATION/DNA

Title:

Cryo-EM structure of a stacked human nucleosome core particle dimer (type 6) assembled with DNA truncated at SHL-5.5

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
Escherichia coli (Taxon ID: 562)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

5.52 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Histone H3.1
Gene (Uniprot):H3C1, H3C2, H3C3, H3C4, H3C6, H3C7, H3C8, H3C10, H3C11, H3C12
Chain IDs:A, E, K, O
Chain Length:135
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P68431 Pfam ID:PF00125

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Histone H4
Gene (Uniprot):H4C1, H4C2, H4C3, H4C4, H4C5, H4C6, H4C8, H4C9, H4C11, H4C12, H4C13, H4C14, H4C15, H4C16
Chain IDs:B, F, L, P
Chain Length:102
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P62805 Pfam ID:PF15511

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Histone H2A type 1-D
Gene (Uniprot):H2AC7
Chain IDs:C, G, M, Q
Chain Length:129
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P20671 Pfam ID:PF00125, PF16211

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Histone H2B type 2-E
Gene (Uniprot):H2BC21
Chain IDs:D, H, N, R
Chain Length:125
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:Q16778 Pfam ID:PF00125

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (129-MER)
Chain IDs:I, S
Chain Length:129
Number of Molecules:2
Biological Source:Escherichia coli

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (129-MER)
Chain IDs:J, T
Chain Length:129
Number of Molecules:2
Biological Source:Escherichia coli

Ligand Molecules

Primary Citation

Structural basis for nucleosome stacking diversity mediated by solvent-exposed histone interfaces

Mu, Z, Huang, J.Show

To Be Published ? ? ? (?)
