9VVJ image
Deposition Date 2025-07-15
Release Date 2026-03-25
Last Version Date 2026-03-25
Entry Detail
PDB ID:
9VVJ
Keywords:
MEMBRANE PROTEIN
Title:
Cryo-EM structure of the erlin1/2 complex purified using DDM and GDN
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.60 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9VVJ validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Erlin-1
Gene (Uniprot):ERLIN1
Chain IDs:A, C (auth: M), E (auth: L), F (auth: K), I (auth: F), K (auth: E), L (auth: D), N (auth: C), O (auth: B), S (auth: J), T (auth: I), V (auth: H), W (auth: G)
Chain Length:304
Number of Molecules:13
Biological Source:Homo sapiens
UniProt ID:O75477 Pfam ID:PF01145
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Erlin-2
Gene (Uniprot):ERLIN2
Chain IDs:B (auth: a), D (auth: m), G (auth: k), H (auth: l), J (auth: f), M (auth: d), P (auth: b), Q (auth: c), R (auth: e), U (auth: i), X (auth: g), Y (auth: h), Z (auth: j)
Chain Length:304
Number of Molecules:13
Biological Source:Homo sapiens
UniProt ID:O94905 Pfam ID:PF01145
Ligand Molecules
NA
Primary Citation
The Erlin1/2 complex is a dynamic scaffold for membrane microdomain assembly on the endoplasmic reticulum
Mol.Cell ? ? ? (2026)
Primary Citation of related structures
9VVJ
