9VTL image
Deposition Date 2025-07-10
Release Date 2026-07-15
Last Version Date 2026-07-15
Entry Detail
PDB ID:
9VTL
Keywords:
VIRAL PROTEIN
Title:
Crystal Structure of the SARS-CoV-2 (COVID-19) main protease with inhibitor AD06cn
Biological Source:
Source Organism(s):
Severe acute respiratory syndrome coronavirus 2 (Taxon ID: 2697049)
synthetic construct (Taxon ID: 32630)
Expression System(s):
Escherichia coli 'bl21-gold(de3)plyss ag'
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.97 Å
R-Value Free:
0.26
R-Value Work:
0.21
Space Group:
I 1 2 1
9VTL validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:3C-like proteinase nsp5
Gene (Uniprot):rep
Chain IDs:A
Chain Length:306
Number of Molecules:1
Biological Source:Severe acute respiratory syndrome coronavirus 2
UniProt ID:P0DTD1 Pfam ID:PF05409 EC:2.7.7.48
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:inhibitor AD06cn
Chain IDs:B
Chain Length:4
Number of Molecules:1
Biological Source:synthetic construct
Primary Citation
Crystal Structure of the SARS-CoV-2 (COVID-19) main protease with inhibitor AD06cn
To Be Published ? ? ? (?)
