ISDA: 9VPD

Deposition Date 2025-07-03

Release Date 2026-07-01

Last Version Date 2026-07-01

Entry Detail

PDB ID:

9VPD

Keywords:

MEMBRANE PROTEIN

Title:

Cryo-EM structure of the IF1 bound bovine ATP synthase monomer: rotary state 1, F1 focused map

Biological Source:

Source Organism(s):

Bos taurus (Taxon ID: 9913)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.30 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1A
Chain IDs:A, B, C
Chain Length:553
Number of Molecules:3
Biological Source:Bos taurus

UniProt ID:P19483 Pfam ID:PF02874, PF00006, PF00306 EC:7.1.2.2

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex cat
Gene (Uniprot):ATP5F1B
Chain IDs:D, E, F
Chain Length:528
Number of Molecules:3
Biological Source:Bos taurus

UniProt ID:P00829 Pfam ID:PF02874, PF00006, PF22919 EC:7.1.2.2

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1C
Chain IDs:G
Chain Length:298
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P05631 Pfam ID:PF00231

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1D
Chain IDs:H
Chain Length:168
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P05630 Pfam ID:PF02823, PF21335

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1E
Chain IDs:I
Chain Length:51
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P05632 Pfam ID:PF04627

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATPase inhibitor, mitochondri
Gene (Uniprot):ATP5IF1
Chain IDs:J
Chain Length:109
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P01096 Pfam ID:PF04568

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PO
Chain IDs:K (auth: S)
Chain Length:213
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P13621 Pfam ID:PF00213

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PB
Chain IDs:L (auth: b)
Chain Length:256
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P13619 Pfam ID:PF05405

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PD
Chain IDs:M (auth: d)
Chain Length:528
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P13620 Pfam ID:PF05873

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PF
Chain IDs:N (auth: h)
Chain Length:168
Number of Molecules:1
Biological Source:Bos taurus

UniProt ID:P02721 Pfam ID:PF05511

Ligand Molecules
