9VPC image
Deposition Date 2025-07-03
Release Date 2026-07-01
Last Version Date 2026-07-15
Entry Detail
PDB ID:
9VPC
Keywords:
MEMBRANE PROTEIN
Title:
Cryo-EM structure of the IF1 bound bovine ATP synthase tetramer
Biological Source:
Source Organism(s):
Bos taurus (Taxon ID: 9913)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
7.20 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9VPC validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):MT-ATP8
Chain IDs:A (auth: 18), DA (auth: 28), GB (auth: 38), JC (auth: 48)
Chain Length:66
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P03929 Pfam ID:PF00895
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase subunit alpha
Gene (Uniprot):ATP5F1A
Chain IDs:B (auth: 1A), C (auth: 1B), D (auth: 1C), EA (auth: 2A), FA (auth: 2B), GA (auth: 2C), HB (auth: 3A), IB (auth: 3B), JB (auth: 3C), KC (auth: 4A), LC (auth: 4B), MC (auth: 4C)
Chain Length:553
Number of Molecules:12
Biological Source:Bos taurus
UniProt ID:F1MLB8 Pfam ID:PF02874, PF00006, PF00306
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex cat
Gene (Uniprot):ATP5F1B
Chain IDs:E (auth: 1D), F (auth: 1E), G (auth: 1F), HA (auth: 2D), IA (auth: 2E), JA (auth: 2F), KB (auth: 3D), LB (auth: 3E), MB (auth: 3F), NC (auth: 4D), OC (auth: 4E), PC (auth: 4F)
Chain Length:528
Number of Molecules:12
Biological Source:Bos taurus
UniProt ID:P00829 Pfam ID:PF02874, PF00006, PF22919 EC:7.1.2.2
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1C
Chain IDs:H (auth: 1G), KA (auth: 2G), NB (auth: 3G), QC (auth: 4G)
Chain Length:298
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P05631 Pfam ID:PF00231
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1D
Chain IDs:I (auth: 1H), LA (auth: 2H), OB (auth: 3H), RC (auth: 4H)
Chain Length:168
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P05630 Pfam ID:PF02823, PF21335
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1E
Chain IDs:J (auth: 1I), MA (auth: 2I), PB (auth: 3I), SC (auth: 4I)
Chain Length:51
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P05632 Pfam ID:PF04627
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATPase inhibitor, mitochondri
Gene (Uniprot):ATP5IF1
Chain IDs:K (auth: 1J), NA (auth: 2J), QB (auth: 3J), TC (auth: 4J)
Chain Length:109
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P01096 Pfam ID:PF04568
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MC2
Chain IDs:L (auth: 1K), M (auth: 1L), N (auth: 1M), O (auth: 1N), P (auth: 1O), Q (auth: 1P), R (auth: 1Q), S (auth: 1R), OA (auth: 2K), PA (auth: 2L), QA (auth: 2M), RA (auth: 2N), SA (auth: 2O), TA (auth: 2P), UA (auth: 2Q), VA (auth: 2R), RB (auth: 3K), SB (auth: 3L), TB (auth: 3M), UB (auth: 3N), VB (auth: 3O), WB (auth: 3P), XB (auth: 3Q), YB (auth: 3R), UC (auth: 4K), VC (auth: 4L), WC (auth: 4M), XC (auth: 4N), YC (auth: 4O), ZC (auth: 4P), AD (auth: 4Q), BD (auth: 4R)
Chain Length:143
Number of Molecules:32
Biological Source:Bos taurus
UniProt ID:P07926 Pfam ID:PF00137
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PO
Chain IDs:T (auth: 1S), WA (auth: 2S), ZB (auth: 3S), CD (auth: 4S)
Chain Length:213
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P13621 Pfam ID:PF00213
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):MT-ATP6
Chain IDs:U (auth: 1a), XA (auth: 2a), AC (auth: 3a), DD (auth: 4a)
Chain Length:226
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P00847 Pfam ID:PF00119
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PB
Chain IDs:V (auth: 1b), YA (auth: 2b), BC (auth: 3b), ED (auth: 4b)
Chain Length:256
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P13619 Pfam ID:PF05405
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PD
Chain IDs:W (auth: 1d), ZA (auth: 2d), CC (auth: 3d), FD (auth: 4d)
Chain Length:161
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P13620 Pfam ID:PF05873
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5ME
Chain IDs:X (auth: 1e), AB (auth: 2e), DC (auth: 3e), GD (auth: 4e)
Chain Length:71
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:Q00361 Pfam ID:PF05680
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MF
Chain IDs:Y (auth: 1f), BB (auth: 2f), EC (auth: 3f), HD (auth: 4f)
Chain Length:88
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:Q28851 Pfam ID:PF10206
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MG
Chain IDs:Z (auth: 1g), CB (auth: 2g), FC (auth: 3g), ID (auth: 4g)
Chain Length:103
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:Q28852 Pfam ID:PF04718
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PF
Chain IDs:AA (auth: 1h), DB (auth: 2h), GC (auth: 3h), JD (auth: 4h)
Chain Length:108
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P02721 Pfam ID:PF05511
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MJ
Chain IDs:BA (auth: 1j), EB (auth: 2j), HC (auth: 3j), KD (auth: 4j)
Chain Length:60
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:P14790 Pfam ID:PF08039
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MK
Chain IDs:CA (auth: 1k), FB (auth: 2k), IC (auth: 3k), LD (auth: 4k)
Chain Length:58
Number of Molecules:4
Biological Source:Bos taurus
UniProt ID:Q3ZBI7 Pfam ID:PF14960
Ligand Molecules
NA
Primary Citation
A planar dimer of bovine ATP synthase.
Cell Death Differ. ? ? ? (2026)
PMID: 42399642 DOI: 10.1038/s41418-026-01797-4
Primary Citation of related structures
9VPC
