9VHM image
Deposition Date 2025-06-17
Release Date 2026-04-29
Last Version Date 2026-06-03
Entry Detail
PDB ID:
9VHM
Title:
structure of CC2D1A (coiled-coil and C2 domain containing - 1A)
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.30 Å
R-Value Free:
0.27
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
P 21 21 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Coiled-coil and C2 domain-con
Gene (Uniprot):CC2D1A
Chain IDs:A, B
Chain Length:320
Number of Molecules:2
Biological Source:Homo sapiens
Primary Citation
Structural characterization of the human CC2D1A fragment associated with non-syndromic intellectual disability (NSID).
Biosci.Rep. 46 ? ? (2026)
PMID: 42047282 DOI: 10.1042/BSR20253955

Abstact

CC2D1A is a multidomain scaffold protein implicated in transcriptional regulation and autosomal recessive non-syndromic intellectual disability (NSID), yet its molecular mechanism is still poorly understood due to a lack of structural information. Here, we present the crystal structure of the human CC2D1A491-810 fragment, encompassing the fourth DM14 domain, a coiled-coil region, and a C-terminal C2 domain. These elements form a compact, integrated architecture, with the C2 domain mediating symmetric dimerization through conserved electrostatic interactions. In addition, a unique antiparallel beta1-beta10 sheet connects the coiled-coil and C2 domains, stabilizing the tertiary structure. Fluorescence polarization assays reveal micromolar DNA-binding affinity, likely mediated by the basic surface of the DM14 domain. Comparison with the Drosophila homolog Lgd highlights conserved topology with added structural features, offering insights into CC2D1A's vertebrate-specific functions and NSID-related mutations.
