ISDA: 9V7C

Deposition Date 2025-05-27

Release Date 2026-06-03

Last Version Date 2026-06-03

Entry Detail

PDB ID:

9V7C

Keywords:

PROTEIN FIBRIL

Title:

The cryo-EM structure of FD4_orientation2 bound Lewy fold fibril.

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.30 Å

Aggregation State:

FILAMENT

Reconstruction Method:

HELICAL

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Alpha-synuclein
Gene (Uniprot):SNCA
Chain IDs:A (auth: c), B (auth: d), C (auth: e), D (auth: f), E (auth: g), F (auth: h), G (auth: i), H (auth: j), I (auth: k), J (auth: o), K (auth: p), L (auth: q), M (auth: r), N (auth: s), O (auth: t)
Chain Length:69
Number of Molecules:15
Biological Source:Homo sapiens

UniProt ID:P37840 Pfam ID:PF01387

Ligand Molecules

A1EFL

Primary Citation

The cryo-EM structure of FD4_orientation2 bound Lewy fold fibril.

Zhao, Q.Y, Cui, B.Y, Liu, C, Li, D.Show

To Be Published ? ? ? (?)

Primary Citation of related structures
