9SOH image
Deposition Date 2025-09-12
Release Date 2026-02-18
Last Version Date 2026-02-18
Entry Detail
PDB ID:
9SOH
Keywords:
LIGASE
Title:
CTLH-CRA domains of the Maea-RanBP10 mutant (Q519G, F543L, Y548F and V556F) complex
Biological Source:
Source Organism(s):
Mus musculus (Taxon ID: 10090)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
3.55 Å
R-Value Free:
0.29
R-Value Work:
0.28
R-Value Observed:
0.28
Space Group:
F 41 3 2
9SOH validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ran-binding protein 10
Gene (Uniprot):Ranbp10
Chain IDs:A, C, E, F (auth: G)
Chain Length:146
Number of Molecules:4
Biological Source:Mus musculus
UniProt ID:Q6VN19 Pfam ID:PF10607
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:E3 ubiquitin-protein transfer
Gene (Uniprot):Maea
Chain IDs:B, D, G (auth: H), H (auth: F)
Chain Length:126
Number of Molecules:4
Biological Source:Mus musculus
UniProt ID:Q4VC33 Pfam ID:PF10607 EC:2.3.2.27
Ligand Molecules
NA
Primary Citation
Engineering CTLH-CRA domains with swapped binding specificity
To be published ? ? ? (?)
Primary Citation of related structures
9SOH
