9RWZ image
Deposition Date 2025-07-10
Release Date 2026-03-18
Last Version Date 2026-04-29
Entry Detail
PDB ID:
9RWZ
Keywords:
Title:
ZSWIM8-CUL3 complex bound to AGO2-miR-7-CYRANO
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Method Details:
Experimental Method:
Resolution:
3.10 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Protein argonaute-2
Gene (Uniprot):AGO2
Chain IDs:A
Chain Length:870
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Elongin-B
Gene (Uniprot):ELOB
Chain IDs:B, C
Chain Length:118
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Elongin-C
Gene (Uniprot):ELOC
Chain IDs:D, E
Chain Length:112
Number of Molecules:2
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:miR-7
Chain IDs:F (auth: G)
Chain Length:24
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cullin-3
Gene (Uniprot):CUL3
Mutagens:I342R, L346D
Chain IDs:G (auth: H), H (auth: I)
Chain Length:396
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Zinc finger SWIM domain-conta
Gene (Uniprot):ZSWIM8
Chain IDs:J (auth: N), K (auth: M)
Chain Length:1866
Number of Molecules:2
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:CYRANO trigger RNA
Chain IDs:I (auth: T)
Chain Length:120
Number of Molecules:1
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
The E3 ubiquitin ligase mechanism specifying targeted microRNA degradation.
Nature 652 784 793 (2026)
PMID: 41851464 DOI: 10.1038/s41586-026-10232-0

Abstact

MicroRNAs (miRNAs) associate with Argonaute (AGO) proteins to form complexes that down-regulate target RNAs, including messenger RNAs from most human genes(1-3). Within each complex, the miRNA pairs to target RNAs, and AGO provides effector function while also protecting the miRNA from cellular nucleases(2-5). Although much is known about miRNA-directed gene regulation, less is known about how miRNAs themselves are regulated. One pathway that regulates miRNAs involves unusual targets called 'trigger' RNAs, which reverse the canonical regulatory logic and instead down-regulate miRNAs(6-9). This target-directed miRNA degradation (TDMD) is thought to require a cullin-RING E3 ligase because it depends on the cullin protein CUL3 and other ubiquitylation components, including the BC-box protein ZSWIM8 (refs. (10,11)). ZSWIM8 is required for murine perinatal viability and for destabilization of most short-lived miRNAs, which suggests biological importance of TDMD(11-13). Here, biochemical and cellular assays establish AGO binding and polyubiquitylation by the ZSWIM8-CUL3 E3 ligase as the key regulatory steps of TDMD, and thereby define a unique cullin-RING E3 ligase class. Cryogenic electron microscopy analyses show ZSWIM8 recognizing distinct AGO and RNA conformations shaped by pairing of the miRNA to the trigger. Specificity of AGO ubiquitylation is established through generalizable RNA-RNA, RNA-protein and protein-protein interactions. The substrate features recognized by the E3 ligase do not conform to a conventional degron(14,15) but instead establish a two-RNA-factor authentication mechanism for specifying a protein ubiquitylation substrate.
