9R19 image
Deposition Date 2025-04-25
Release Date 2025-09-17
Last Version Date 2026-04-01
Entry Detail
PDB ID:
9R19
Keywords:
Title:
Crystal structure of human ACE2 in complex with VHH B07 and VHH B10
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Vicugna pacos (Taxon ID: 30538)
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.69 Å
R-Value Free:
0.25
R-Value Work:
0.21
R-Value Observed:
0.22
Space Group:
P 1 21 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Processed angiotensin-convert
Gene (Uniprot):ACE2
Chain IDs:A, B, C
Chain Length:604
Number of Molecules:3
Biological Source:Homo sapiens
Protein Blast
Polymer Type:polypeptide(L)
Molecule:VHH B10
Chain IDs:D, E, F
Chain Length:153
Number of Molecules:3
Biological Source:Vicugna pacos
Protein Blast
Polymer Type:polypeptide(L)
Molecule:VHH B07
Chain IDs:G, H, I
Chain Length:143
Number of Molecules:3
Biological Source:Vicugna pacos
Primary Citation
Targeting ACE2 with a camelid antibody inhibits SARS-CoV-2 binding and has protective effects in vivo.
Nat Commun 16 10268 10268 (2025)
PMID: 41271706 DOI: 10.1038/s41467-025-65144-w

Abstact

The continuous emergence of antibody-escape variants of SARS-CoV-2 demands the identification of alternative methods of protection against infection that do not directly target viral proteins. Here, we generated heavy-chain-only antibody (VHHs) from an alpaca immunized with the human angiotensin-converting enzyme 2 (hACE2), the major entry receptor for SARS-CoV-2. The VHHs bind hACE2 without affecting its enzymatic activity, and two of them (B07 and B09) inhibit all SARS-CoV-2 isolates tested (Delta, BA.1, BQ1.1, XBB.1.5, XBB.1.16.1, EG.5.1.3, BA.2.86.1). Their X-ray structure in complex with hACE2 show that their epitope overlaps with the footprint of the receptor binding domain (RBD) of the SARS-CoV-2 spike on hACE2. A dimeric B07-Fc fusion construct avidly binds hACE2 with an apparent dissociation constant of 0.1 nM and inhibits in vitro infection of previously tested variants and, of JN.1.1 and KP.3.3 variants, with an IC50 ~ 1 nM. In vivo experiments using K18-hACE2 mice show that intranasal prophylactic administration of B07-Fc confer a dose-dependent protection against SARS-CoV-2 D614G and Omicron variants. These VHHs targeting hACE2 represent potential broad-spectrum therapeutic candidates against potential new emerging coronaviruses using hACE2 as a receptor.
