9QLV image
Deposition Date 2025-03-21
Release Date 2026-04-08
Last Version Date 2026-05-13
Entry Detail
PDB ID:
9QLV
Keywords:
PLANT PROTEIN
Title:
Cryo-EM structure of Arabidopsis TIR-NLR WRR4A tetramer in complex with effector CCG40
Biological Source:
Source Organism(s):
Albugo candida (Taxon ID: 65357)
Arabidopsis thaliana (Taxon ID: 3702)
Expression System(s):
Nicotiana benthamiana
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.50 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9QLV validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Disease resistance protein AD
Gene (Uniprot):ADR2
Chain IDs:E (auth: A), F (auth: B), G (auth: C), H (auth: D)
Chain Length:1007
Number of Molecules:4
Biological Source:Arabidopsis thaliana
UniProt ID:Q9C7X0 EC:3.2.2.6
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CCG40
Chain IDs:A (auth: P), B (auth: Q), C (auth: R), D (auth: S)
Chain Length:216
Number of Molecules:4
Biological Source:Albugo candida
UniProt ID:A0A8F4TCV5
Ligand Molecules
ADP
Primary Citation
Structural basis for the broad recognition specificity of an Arabidopsis immune receptor
Biorxiv ? ? ? (2026)
DOI: 10.64898/2026.02.04.703898
Primary Citation of related structures
9QLV
