ISDA: 9Q2L

Deposition Date 2025-08-15

Release Date 2026-07-22

Last Version Date 2026-07-22

Entry Detail

PDB ID:

9Q2L

Keywords:

DNA BINDING PROTEIN/DNA

Title:

Rad55-Rad57(E161Q)-SHU-3xRad51 bound to ssDNA with ATP

Biological Source:

Source Organism(s):

Saccharomyces cerevisiae (Taxon ID: 4932)
synthetic construct (Taxon ID: 32630)

Expression System(s):

Trichoplusia ni

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.70 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Methylated-DNA--protein-cyste
Chain IDs:A
Chain Length:631
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae

UniProt ID:E5BBQ0,P38953 Pfam ID:PF06745 EC:2.1.1.63

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:DNA repair protein RAD57
Gene (Uniprot):RAD57
Mutagens:E161Q
Chain IDs:B
Chain Length:460
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae

UniProt ID:P25301 Pfam ID:PF08423

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Chromosome segregation in mei
Gene (Uniprot):CSM2
Chain IDs:C
Chain Length:213
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae

UniProt ID:P40465 Pfam ID:PF16834

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Platinum sensitivity protein
Gene (Uniprot):PSY3
Chain IDs:D
Chain Length:281
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae

UniProt ID:Q12318 Pfam ID:PF16836

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Suppressor of HU sensitivity
Gene (Uniprot):SHU1
Chain IDs:E
Chain Length:150
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae

UniProt ID:P38751

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Suppressor of hydroxyurea sen
Chain IDs:F
Chain Length:262
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae

UniProt ID:C7GVQ9

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:DNA repair protein RAD51
Gene (Uniprot):RAD51
Chain IDs:G, I, J
Chain Length:418
Number of Molecules:3
Biological Source:Saccharomyces cerevisiae

UniProt ID:P25454 Pfam ID:PF14520, PF08423

Polymer Type:polydeoxyribonucleotide
Molecule:ssDNA (13-mer)
Chain IDs:H
Chain Length:13
Number of Molecules:1
Biological Source:synthetic construct

Ligand Molecules
