ISDA: 9PIN

Deposition Date 2025-07-10

Release Date 2026-07-22

Last Version Date 2026-07-22

Entry Detail

PDB ID:

9PIN

Keywords:

PROTEIN FIBRIL

Title:

Inner Curvature of Thick Flagellar Filament from T.denticola

Biological Source:

Source Organism(s):

Treponema denticola ATCC 35405 (Taxon ID: 243275)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.90 Å

Aggregation State:

PARTICLE

Reconstruction Method:

HELICAL

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellar filament outer laye
Gene (Uniprot):TDE_1409
Chain IDs:A (auth: A0), C (auth: A4), E (auth: A6), J (auth: BI), K (auth: BJ), N (auth: BM)
Chain Length:246
Number of Molecules:6
Biological Source:Treponema denticola ATCC 35405

UniProt ID:Q73MU8 Pfam ID:PF04620

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellar filament outer laye
Gene (Uniprot):flaA
Chain IDs:B (auth: A3), D (auth: A5), H (auth: A9), P (auth: BQ), Q (auth: BR), R (auth: BS)
Chain Length:349
Number of Molecules:6
Biological Source:Treponema denticola ATCC 35405

UniProt ID:Q73M00 Pfam ID:PF04620

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellar filament outer laye
Gene (Uniprot):TDE_1408
Chain IDs:F (auth: A7), G (auth: A8), I (auth: BA), L (auth: BK), M (auth: BL), O (auth: BN)
Chain Length:236
Number of Molecules:6
Biological Source:Treponema denticola ATCC 35405

UniProt ID:Q73MU9 Pfam ID:PF04620

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Flagellin
Gene (Uniprot):TDE_1004
Chain IDs:Y (auth: C0), Z (auth: DA), AA (auth: DB), BA (auth: DC), CA (auth: DD), DA (auth: DE), EA (auth: DF), FA (auth: DG), GA (auth: DH), HA (auth: DI), IA (auth: DJ), JA (auth: DK), KA (auth: DL), LA (auth: DM), MA (auth: DN), NA (auth: DO), OA (auth: DP), PA (auth: DQ)
Chain Length:286
Number of Molecules:18
Biological Source:Treponema denticola ATCC 35405

UniProt ID:Q73NZ6 Pfam ID:PF00669, PF00700

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:FlaL2
Chain IDs:S (auth: E), T (auth: F), U (auth: G)
Chain Length:139
Number of Molecules:3
Biological Source:Treponema denticola ATCC 35405

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:HEAT repeat domain-containing
Chain IDs:V (auth: P2), W (auth: P3), X (auth: P4)
Chain Length:234
Number of Molecules:3
Biological Source:Treponema denticola ATCC 35405

Ligand Molecules

A1CIM

Primary Citation

Structural basis of biofilm formation by the oral pathogen Treponema denticola

Troman, L.A, Paul, B.Show

To Be Published ? ? ? (?)
