ISDA: 9OU4

Deposition Date 2025-05-28

Release Date 2026-06-17

Last Version Date 2026-06-17

Entry Detail

PDB ID:

9OU4

Keywords:

HYDROLASE

Title:

K-Ras Wild Type 1-169 bound to BI-2865 at 313 K

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)

Expression System(s):

Escherichia coli bl21(de3)

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

1.89 Å

R-Value Free:

0.22

R-Value Work:

0.18

R-Value Observed:

0.18

Space Group:

P 21 2 21

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Isoform 2B of GTPase K-Ras
Gene (Uniprot):KRAS
Chain IDs:A
Chain Length:169
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P01116 Pfam ID:PF00071 EC:3.6.5.2

Ligand Molecules

GDP

OFU

Primary Citation

Inhibitor-Bound Structures of K-Ras at Different Temperatures

Xu, M, Deck, S.L, Milano, S.K, Cerione, R.A.Show

To Be Published ? ? ? (?)

Primary Citation of related structures
