9O4E image
Deposition Date 2025-04-08
Release Date 2026-05-06
Last Version Date 2026-05-06
Entry Detail
PDB ID:
9O4E
Keywords:
ANTIVIRAL PROTEIN
Title:
EcAvs2 bound to phage PhiV-1 terminase
Biological Source:
Source Organism(s):
Escherichia coli (Taxon ID: 562)
Escherichia phage PhiV-1 (Taxon ID: 2744002)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.33 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9O4E validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:AVAST type 2 anti-phage syste
Chain IDs:A, B, C, D
Chain Length:1484
Number of Molecules:4
Biological Source:Escherichia coli
UniProt ID:9O4E
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Terminase, large subunit
Chain IDs:E, F, G, H
Chain Length:586
Number of Molecules:4
Biological Source:Escherichia phage PhiV-1
UniProt ID:A0A7G3WWS0 Pfam ID:PF22530
Ligand Molecules
ATP
MG
Primary Citation
Structural basis of phage terminase recognition by the bacterial immune receptor Avs2
To Be Published ? ? ? (?)
Primary Citation of related structures
9O4E
