ISDA: 9NV6

Deposition Date 2025-03-20

Release Date 2026-07-29

Last Version Date 2026-07-29

Entry Detail

PDB ID:

9NV6

Keywords:

IMMUNE SYSTEM

Title:

Crystal structure of NP101 TCR in complex with NP366-H-2Db

Biological Source:

Source Organism(s):

Mus musculus (Taxon ID: 10090)
Influenza A virus (Taxon ID: 11320)

Expression System(s):

Homo sapiens, Escherichia coli bl21(de3)

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

2.18 Å

R-Value Free:

0.25

R-Value Work:

0.19

R-Value Observed:

0.20

Space Group:

P 1

Download Validation Report

Macromolecular Entities

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:NP101 TCR alpha-chain
Chain IDs:A
Chain Length:223
Number of Molecules:1
Biological Source:Mus musculus

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:NP101 TCR beta-chain
Chain IDs:B
Chain Length:254
Number of Molecules:1
Biological Source:Mus musculus

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:H-2 class I histocompatibilit
Gene (Uniprot):H2-D1
Chain IDs:C
Chain Length:281
Number of Molecules:1
Biological Source:Mus musculus

UniProt ID:P01899 Pfam ID:PF00129, PF07654

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Beta-2-microglobulin
Gene (Uniprot):B2m
Chain IDs:D
Chain Length:100
Number of Molecules:1
Biological Source:Mus musculus

UniProt ID:P01887 Pfam ID:PF07654

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Nucleoprotein peptide
Gene (Uniprot):NP
Chain IDs:E (auth: P)
Chain Length:9
Number of Molecules:1
Biological Source:Influenza A virus

UniProt ID:Q9Q0U8

Ligand Molecules
