9NO4 image
Deposition Date 2025-03-07
Release Date 2025-11-12
Last Version Date 2026-07-29
Entry Detail
PDB ID:
9NO4
Title:
Cryo-EM structure of Csm/AcrIIIA2/enolase 3:2 complex
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.67 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:CRISPR system single-strand-s
Gene (Uniprot):cas10
Chain IDs:R (auth: A)
Chain Length:758
Number of Molecules:1
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:CRISPR system Cms protein Csm
Gene (Uniprot):csm
Chain IDs:A (auth: B)
Chain Length:299
Number of Molecules:1
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:CRISPR system Cms protein Csm
Gene (Uniprot):csm
Chain IDs:F (auth: C), G (auth: D)
Chain Length:130
Number of Molecules:2
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:CRISPR system Cms endoribonuc
Gene (Uniprot):csm
Chain IDs:B (auth: E), C (auth: F)
Chain Length:220
Number of Molecules:2
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:CRISPR system Cms endoribonuc
Gene (Uniprot):csm
Chain IDs:D (auth: G)
Chain Length:220
Number of Molecules:1
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:CRISPR system Cms protein Csm
Gene (Uniprot):csm5
Chain IDs:H
Chain Length:357
Number of Molecules:1
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:Enolase
Gene (Uniprot):eno
Chain IDs:I, J, L (auth: K), M (auth: L), N (auth: M), O, P, Q
Chain Length:434
Number of Molecules:8
Biological Source:Streptococcus thermophilus
Polymer Type:polyribonucleotide
Molecule:crRNA RNA (35-MER)
Chain IDs:E (auth: N)
Chain Length:35
Number of Molecules:1
Biological Source:Streptococcus thermophilus
Polymer Type:polypeptide(L)
Molecule:AcrIIIA2
Gene (Uniprot):CHPC1156_0026
Chain IDs:K (auth: R)
Chain Length:105
Number of Molecules:1
Biological Source:Streptococcus phage 2972
Ligand Molecules
Primary Citation
A phage-encoded anti-CRISPR protein co-opts host enolase to prevent type III CRISPR immunity.
Nat Microbiol 10 3162 3175 (2025)
PMID: 41219509 DOI: 10.1038/s41564-025-02178-2

Abstact

CRISPR (Clustered Regularly Interspaced Short Palindromic Repeats) systems provide powerful adaptive immunity against phage infection. In response, phages use anti-CRISPR (Acr) proteins to evade CRISPR immunity. The few type III Acrs identified so far show conditional effectiveness in countering type III immunity or rely on unknown or poorly understood inhibitory mechanisms. Here we report the discovery of AcrIIIA2, a type III-A Acr encoded by Streptococcus thermophilus phages. Biochemical and structural analyses reveal that phage AcrIIIA2 co-opts host enolase, a highly abundant glycolysis enzyme, to form a ternary complex with the S. thermophilus type III-A (Csm) CRISPR ribonucleoprotein complex, obstructing its immune responses. The enolase-chaperoned AcrIIIA2 blocks the initial step of phage RNA binding, thereby preventing downstream type III anti-phage immune responses. Enolase participates in the anti-immune response by serving as an essential structural scaffold, stabilizing Acr-CRISPR interactions. These findings uncover a new anti-defence strategy that exploits a well-conserved host factor to block CRISPR immunity.
