ISDA: 9N3Y

Deposition Date 2025-02-01

Release Date 2026-08-05

Last Version Date 2026-08-05

Entry Detail

PDB ID:

9N3Y

Keywords:

DNA BINDING PROTEIN

Title:

Type IV-A1 CRISPR effector complex bound to dsDNA and CasDinG - loaded state

Biological Source:

Source Organism(s):

Pseudomonas aeruginosa (Taxon ID: 287)
synthetic construct (Taxon ID: 32630)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.00 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:CRISPR type AFERR-associated
Chain IDs:F (auth: A)
Chain Length:241
Number of Molecules:1
Biological Source:Pseudomonas aeruginosa

UniProt ID:A0AAB0B1U3

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:CCRISPR type AFERR-associated
Chain IDs:A (auth: B)
Chain Length:220
Number of Molecules:1
Biological Source:Pseudomonas aeruginosa

UniProt ID:A0AAB0B1V2

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:CRISPR type AFERR-associated
Chain IDs:G (auth: C), H (auth: D), I (auth: E), J (auth: F), K (auth: G)
Chain Length:359
Number of Molecules:5
Biological Source:Pseudomonas aeruginosa

UniProt ID:A0AAB0B1V3

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:CRISPR type AFERR-associated
Chain IDs:B (auth: H)
Chain Length:232
Number of Molecules:1
Biological Source:Pseudomonas aeruginosa

UniProt ID:A0AAB0B1V7

Polymer Type:polyribonucleotide
Molecule:crRNA (61-MER)
Chain IDs:C (auth: I)
Chain Length:61
Number of Molecules:1
Biological Source:Pseudomonas aeruginosa

Polymer Type:polydeoxyribonucleotide
Molecule:DNA, non-target strand (48-ME
Chain IDs:D (auth: J)
Chain Length:54
Number of Molecules:1
Biological Source:synthetic construct

Polymer Type:polydeoxyribonucleotide
Molecule:DNA, target strand (48-MER)
Chain IDs:E (auth: K)
Chain Length:54
Number of Molecules:1
Biological Source:synthetic construct

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:CRISPR-associated DEAD/DEAH-b
Chain IDs:L
Chain Length:748
Number of Molecules:1
Biological Source:Pseudomonas aeruginosa

UniProt ID:A0AA82WPF0

Ligand Molecules

Primary Citation

Locked and loaded: mechanisms of CasDinG recruitment to the type IV-A1 CRISPR effector complex

Kiernan, K.A, Taylor, D.W.Show

To Be Published ? ? ? (?)
