9LQO image
Deposition Date 2025-01-28
Release Date 2026-08-05
Last Version Date 2026-08-05
Entry Detail
PDB ID:
9LQO
Keywords:
DNA BINDING PROTEIN/DNA
Title:
Structure of RAG transposon end complex (TEC)
Biological Source:
Source Organism(s):
Mus musculus (Taxon ID: 10090)
synthetic construct (Taxon ID: 32630)
Expression System(s):
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.00 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9LQO validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:V(D)J recombination-activatin
Gene (Uniprot):Rag1
Mutagens:E662A, S721A, S723A, and R848M
Chain IDs:A, C
Chain Length:750
Number of Molecules:2
Biological Source:Mus musculus
UniProt ID:P15919 Pfam ID:PF00097, PF10426, PF12940, PF26024, PF26025, PF26100, PF26101, PF26104, PF26105 EC:3.1.-.-,2.3.2.27
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:V(D)J recombination-activatin
Gene (Uniprot):Rag2
Mutagens:K58E and K119A
Chain IDs:B, D
Chain Length:363
Number of Molecules:2
Biological Source:Mus musculus
UniProt ID:P21784 Pfam ID:PF03089
Polymer Type:polydeoxyribonucleotide
Molecule:12RSS bottom strand
Chain IDs:E (auth: F)
Chain Length:34
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:23RSS bottom strand
Chain IDs:G
Chain Length:45
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:12RSS top strand
Chain IDs:F (auth: L)
Chain Length:34
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:23RSS top strand
Chain IDs:H (auth: M)
Chain Length:45
Number of Molecules:1
Biological Source:synthetic construct
Ligand Molecules
MG
ZN
Primary Citation
Structural basis and dynamics of target capture and integration during cut-and-paste transposition
To Be Published ? ? ? (?)
