9HVS image
Deposition Date 2025-01-02
Release Date 2026-07-15
Last Version Date 2026-07-15
Entry Detail
PDB ID:
9HVS
Keywords:
LYASE
Title:
Orotidine 5'-monophosphate decarboxylase-domain of human UMPS in complex with 6-Ethyl UMP
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli bl21(de3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.30 Å
R-Value Free:
0.16
R-Value Work:
0.15
R-Value Observed:
0.15
Space Group:
C 2 2 21
9HVS validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Uridine 5'-monophosphate synt
Gene (Uniprot):UMPS
Chain IDs:A
Chain Length:258
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P11172 Pfam ID:PF00215 EC:4.1.1.23
Ligand Molecules
PRO
SO4
UEP
Primary Citation
Orotidine 5'-monophosphate decarboxylase-domain of human UMPS in complex with 6-Ethyl UMP
To Be Published ? ? ? (?)
Primary Citation of related structures
9HVS
