9EAZ image
Deposition Date 2024-11-11
Release Date 2026-06-17
Last Version Date 2026-06-17
Entry Detail
PDB ID:
9EAZ
Keywords:
OXIDOREDUCTASE
Title:
CRYSTAL STRUCTURE OF THE FMN-BINDING DOMAIN OF HUMAN CYTOCHROME P450 REDUCTASE (MUTANT A229T)
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli bl21(de3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.17 Å
R-Value Free:
0.17
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
P 1 21 1
9EAZ validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:NADPH--cytochrome P450 reduct
Gene (Uniprot):POR
Mutagens:A229T
Chain IDs:A
Chain Length:191
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P16435 Pfam ID:PF00258 EC:1.6.2.4
Ligand Molecules
CA
FMN
Primary Citation
Structural Insights into Mutant Forms of Human NADPH Cytochrome P450 Reductase FMN Containing Domain via X-ray Crystallography
To Be Published ? ? ? (?)
Primary Citation of related structures
1B1C
