8UG2 image
Deposition Date 2023-10-05
Release Date 2024-10-09
Last Version Date 2026-06-17
Entry Detail
PDB ID:
8UG2
Keywords:
Title:
Crystal structure of de novo designed metal-controlled heterodimer of mutant B1 immunoglobulin-binding domain of Streptococcal Protein G MCHeT_A + MCHeT_C
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
1.36 Å
R-Value Free:
0.17
R-Value Work:
0.14
R-Value Observed:
0.14
Space Group:
I 41
Macromolecular Entities
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Beta 1 domain of streptococca
Chain IDs:A
Chain Length:56
Number of Molecules:1
Biological Source:Streptococcus pyogenes
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Beta 1 domain of streptococca
Mutagens:L12H, T16V, V29E, Y33E, N37V
Chain IDs:B
Chain Length:56
Number of Molecules:1
Biological Source:Streptococcus pyogenes
Primary Citation
Incorporating Metal-Ligand and Salt-Bridge Interactions in the Design of Protein Heterodimers.
Biochemistry 64 3237 3247 (2025)
PMID: 40644321 DOI: 10.1021/acs.biochem.5c00108

Abstact

The design of chemically controlled asymmetric protein-protein interfaces will further enhance the building of precise protein-based biomaterials. Driving protein-protein interactions through engineered metal-ligand coordination and salt-bridge formation enables the reversible association of two unique binding partners. Creation of precise biomaterial is enhanced through the temporal and chemical control afforded by metal-controlled heterodimeric proteins. In addition, heterodimers enable the specific association of different passenger proteins expressed as fusions to the heterodimeric binding partners. To increase the versatility of protein-based tools, we converted a previously engineered metal-controlled homodimer into a metal-controlled heterodimer. To promote specificity of the heterodimer complex and prevent self-association, it was necessary to incorporate elements of positive and negative design, which was achieved through the incorporation of a cross-interface electrostatic interaction, as well as modifications to hydrophobic contacts at the protein-protein interface. The resulting metal-controlled heterodimer binds with low micromolar affinity, and the crystal structures indicate the presence of the designed dual-interaction motifs at the protein-protein interface.
