Deposition Date 2021-06-21
Release Date 2021-12-08
Last Version Date 2024-11-13
Entry Detail
PDB ID:
7NAB
Title:
Crystal structure of human neutralizing mAb CV3-25 binding to SARS-CoV-2 S MPER peptide 1140-1165
Biological Source:
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.15 Å
R-Value Free:
0.23
R-Value Work:
0.18
R-Value Observed:
0.18
Space Group:
P 1 21 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Spike protein S2
Gene (Uniprot):S
Chain IDs:E (auth: D), F (auth: C)
Chain Length:27
Number of Molecules:2
Biological Source:Severe acute respiratory syndrome coronavirus 2
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CV3-25 Fab Heavy Chain
Chain IDs:A (auth: H), C (auth: A)
Chain Length:227
Number of Molecules:2
Biological Source:Homo sapiens
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CV3-25 Fab Light Chain
Chain IDs:B (auth: L), D (auth: B)
Chain Length:213
Number of Molecules:2
Biological Source:Homo sapiens
Primary Citation
Structural basis and mode of action for two broadly neutralizing antibodies against SARS-CoV-2 emerging variants of concern.
Cell Rep 38 110210 110210 (2022)
PMID: 34971573 DOI: 10.1016/j.celrep.2021.110210

Abstact

Emerging variants of concern for the severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) can transmit more efficiently and partially evade protective immune responses, thus necessitating continued refinement of antibody therapies and immunogen design. Here, we elucidate the structural basis and mode of action for two potent SARS-CoV-2 spike (S)-neutralizing monoclonal antibodies, CV3-1 and CV3-25, which remain effective against emerging variants of concern in vitro and in vivo. CV3-1 binds to the (485-GFN-487) loop within the receptor-binding domain (RBD) in the "RBD-up" position and triggers potent shedding of the S1 subunit. In contrast, CV3-25 inhibits membrane fusion by binding to an epitope in the stem helix region of the S2 subunit that is highly conserved among β-coronaviruses. Thus, vaccine immunogen designs that incorporate the conserved regions in the RBD and stem helix region are candidates to elicit pan-coronavirus protective immune responses.
